Printhead Card - HIB-KY-KJ4A/B-0300
Printhead Manufacturer
Kyocera
Printhead Family
KJ4A/B-0300 (U)
Overview
The GIS HIB-KY-KJ4A/B-0300 printhead card assembly is designed to provide communications between the Kyocera KJ4A/B-0300 600dpi printhead and the GIS Printhead Card Manager (PHCM-C8-3)
Printhead Variants Supported
KJ4A/B-0300 300dpi 30kHz
Number of Printheads
1
Print Modes
| Binary | |
| Greyscale |
Dimensions
| Length | 80mm |
| Width | 100mm |
| Depth | 20mm |
| Weight | 85g |
| PC to PHCM Connection Length | up to 5m |
| PHCM to PHC Connection Length | up to 10m |
| PHC to Printhead Connection Length | 300mm |
Control
| Printhead Heater | |
| Thermal Protection |
Monitoring
| Board Temperature | |
| Printhead Temperature |
Connectivity
| Power Supply | |
| Number of Connectors Required to Drive Printhead | 2 |
